Cold Storage Room for Meat and Seafood with Energy- Insulation and Durable Panels

GreenHealth GH-CR Supermarket Walk-in Cold Room

GH-CR is a custom walk-in cold room for supermarket and grocery backroom storage. It holds a large volume of food behind the sales floor: fruit, vegetables, dairy, drinks, fresh meat and frozen food. It is a storage room, not a glass display cabinet on the aisle.

Room type by temperature
• Chiller room: 0°C to +10°C for fruit, vegetables, dairy, drinks and fresh meat
• Freezer room: -18°C to -22°C for frozen food, frozen meat and ice cream stock
• Low-temperature room: -40°C to -25°C when the supermarket needs blast freezing
• Standard project range: -40°C to +10°C

Size
Built to the store drawing. Common volume is 10 m³ to 1000 m³ for convenience stores, supermarkets and hypermarkets. Send the length, width and height of the plant room or backroom. We will confirm panel thickness, unit size and door opening.

Who uses this room
• Supermarket and hypermarket backrooms
• Grocery warehouses attached to the store
• Convenience-store stock rooms
• Fresh-food processing rooms behind the meat or produce counter

What can be stored
• Fruit and vegetables
• Dairy and eggs
• Packaged food and drinks
• Fresh meat and seafood held before display
• Frozen food pallet or shelf stock

What it is not
• Not a supermarket glass-door display freezer
• Not a reach-in kitchen cabinet
• Not an explosion-proof room unless a separate design is quoted

Panel and door
• Insulation: rigid PU foam, foamed in place
• Thickness: 100 / 120 / 150 / 200 mm
• Surface: embossed coated steel inside and outside
• Fire rating of the panel: GB 8624 B2
• Door swing: left-hand or right-hand
• Door opening: 0.8×1.8 m, 1.0×2.0 m, 1.2×2.0 m, or custom for pallet trolleys
• Lock: deadbolt with key and inside safety release
• Floor load: 6 kN/m² for trolley and stacked-goods traffic

Which panel to use in a supermarket
• 100 mm: 0°C to +10°C produce and dairy rooms
• 120 mm: mixed chiller rooms
• 150 mm: -18°C to -22°C frozen-food rooms
• 200 mm: -25°C to -40°C rooms or hot-climate stores

Refrigeration package
• Condensing unit: Copeland, air-cooled
• Evaporator: Keweily air cooler
• Refrigerant: R404A
• Defrost: electric auto defrost
• Controller: digital
• Power: 220V or 380V, 50/60Hz

Order terms
Manufacturer: Guangdong Green&Health Intelligence Cold Chain Technology Co., Ltd., Guangzhou, China.
Certification: CE.
MOQ: 1 set.
Lead time: 25 days after drawing and deposit confirmation.
Packing: wooden packing.
Payment: T/T.
Warranty: 12 months on the refrigeration unit and supplied parts.

Item | GH-CR Supermarket Walk-in Cold Room
Product type | Custom PU-panel walk-in cold room for supermarket bulk storage
Volume | 10–1000 m³, built to store drawing
Typical use | Backroom storage of produce, dairy, drinks, meat and frozen food
Room options | Chiller 0 to +10°C / Freezer -18 to -22°C / Low-temp -40 to -25°C

FAQ

Q1. Are you a factory or a trading company?
A. We are the manufacturer, Guangdong Green&Health Intelligence Cold Chain Technology Co., Ltd., in Guangzhou, China.

Q2. What is this cold room used for?
A. It is a supermarket backroom storage room for bulk food: fruit, vegetables, dairy, drinks, packaged food, fresh meat and frozen food. It is not a glass display cabinet.

Q3. Can it store fresh meat?
A. Yes. Fresh meat can be held in the chiller room before it goes to the display counter. Frozen meat goes in the -18°C to -22°C room.

Q4. What temperature should a supermarket choose?
A. Produce, dairy and fresh meat: 0°C to +10°C. Frozen-food stock: -18°C to -22°C. One room keeps one temperature band. Fresh and frozen stock need two rooms.

Q5. What sizes can you build?
A. From about 10 m³ to 1000 m³, made to the backroom drawing. Send L × W × H and we will confirm the design.

Q6. How do I choose panel thickness?
A. 100 mm for 0°C to +10°C. 150 mm for -18°C freezer rooms. 200 mm for -25°C to -40°C or hot-climate stores.

Q7. Which compressor and refrigerant do you use?
A. Copeland air-cooled condensing unit, Keweily air cooler and R404A as standard. Power is 220V or 380V, 50/60Hz.

Q8. What door sizes are available?
A. 0.8×1.8 m, 1.0×2.0 m and 1.2×2.0 m, left-hand or right-hand. The lock has an inside safety release. Tell us if a trolley must enter.

Q9. What do you need for a quotation?
A. Store type, goods to store, target temperature, room L × W × H, city, and 220V or 380V.

Q10. What is the MOQ, lead time and warranty?
A. MOQ 1 set. Lead time 25 days after drawing confirmation. Payment by T/T. Warranty 12 months on the unit and supplied parts. Certification: CE.
